| specification | NMI 1200 | NMI 1600 | NMI 1800 | NMI 2000 |
|---|---|---|---|---|
| Type of pressing | Table Vibration | Table Vibration | Table Vibration | Table Vibration |
| Pallet size | 450 X 450 mm | 610X610 | - | - |
| Production cycle | 3.5 Frequency per Minute | 3.5 Frequency per Minute | 3.3 Frequency per Minute | 3.2 Frequency per Minute |
| Total Power | 22 HP | 27.5 HP | 35 HP | 37.5 HP |
| Brick size | 230 x 110 x 75 mm (with frog)* | 230 x 110 x 75 mm (with frog)* | 230 x 110 x 75 mm (with frog)* | 230 x 110 x 75 mm (with frog)* |
| Production capacity | 1260 bricks / hour (rated) ** | 1600 bricks / hour (rated) ** | 1800 bricks / hour (rated) ** | 2000 bricks / hour (rated) ** |
| No. Of bricks / stroke | 6bricks / stroke | 8bricks / stroke | 10bricks / stroke | 12bricks / stroke |
| Labour require | 8 | 8 | 10 | 10 |
| Shed require | 55 X 35 X 15FEET | 60 X 40 X 15 FEET | 60 X 40 X 15 FEET | 65 X 45 X 15 FEET |
